ONKA 4mm2 PE spring rail connector terminal block DIN rail terminal 2-wire grey, 1020299

Online payment by card - after completing your order, you will be redirected to the payment gateway, payment confirmation will be sent to you by email

Cash on delivery - payment according to the payment regulations will be made to the delivery person of the transport company

By bank transfer - you will receive a pro forma invoice by email no later than the next working day, on which you will find the account number to enter when paying.

On invoice - this payment option is reserved for partners who have signed a framework contract with our company.

If you wish to use the last 2 methods, please call our manager and he will give you instructions on how to obtain an invoice with or without VAT.

The electrical appliances we supply meet high quality standards, have a 24-month warranty and comply with all EU requirements.

In the event of a complaint, no fees are charged for the return of goods.

PE spring busbar connector / DIN rail terminal 2-wire green-yellow, ONKA, made in Turkey

The compact installation rail couplers from ONKA offer great possibilities for connecting any wire of different sections. The transparent housing allows for easy verification of the correct arrangement of wires. The original ONKA quick fasteners provide installation convenience and 100% connection reliability.

Technical parameters

Connected wire section up to: 4mm2
Color: Green-yellow (camouflage)
Main housing insulating material: polyamide (PA6.6)
Contact/bridge material: steel/copper CK45
Connection position: Top / top
Cable strip length: 9 mm
Electrical connection type: spring clamp
Rated voltage: 750V
Operating temperature range: -40°C... 140°C
Mounting method: DIN rail mounting 35 mm
Standard: EN-60947-7-1
