ONKA 4mm2 PE Terminal for screw rail Terminal for DIN rail 2-wire gray, 1010220
- Regular price
- €2,12
- Regular price
-
- Sale price
- €2,12
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
- Description
- Payment methods
- Warranty
The compact installation rail connectors from ONKA offer great possibilities for connecting any wire of different sections. The transparent housing allows for easy verification of the correct arrangement of wires. ONKA's original quick connectors facilitate installation and ensure 100% connection reliability.
Technical parameters
Connected wire section up to: 4mm2
Color: Green-yellow (camouflage)
Main housing insulating material: polyamide (PA6.6)
Contact/bridge material: steel/copper CK45
Tightening torque: 0.5 Nm
Connection position: Side / Side
Stripping length of cable: 9 mm
Type of electrical connection: screw collar
Rated voltage: 750V
Operating temperature range: -40°C... 140°C
Mounting method: DIN mounting rail 35 mm
Standard: EN-60947-7-1
