ONKA 10mm2 spring rail connector terminal strip DIN rail terminal strip 2-wire grey, 1020044
Online payment by card - after completing your order, you will be redirected to the payment gateway, payment confirmation will be sent to you by email
Cash on delivery - payment according to the payment regulations will be made to the delivery person of the transport company
By bank transfer - you will receive a pro forma invoice by email no later than the next working day, on which you will find the account number to enter when paying.
On invoice - this payment option is reserved for partners who have signed a framework contract with our company.
If you wish to use the last 2 methods, please call our manager and he will give you instructions on how to obtain an invoice with or without VAT.
The electrical appliances we supply meet high quality standards, have a 24-month warranty and comply with all EU requirements.
In the event of a complaint, no fees are charged for the return of goods.
ONKA's compact installation rail couplers offer great possibilities for connecting any wire of different sections. The transparent housing allows for easy verification of the correct arrangement of wires. ONKA's original quick connectors facilitate installation and ensure 100% connection reliability. Technical parameters Connected wire section up to: 10mm2
Color: gray
Main housing insulating material: polyamide (PA6.6)
Contact/jumper material: stainless steel/copper
Connection position: top / top
Cable strip length: 12 mm
Type of electrical connection: spring clamp / retractable contact
Rated voltage: 750V
Rated current: 57A
Operating temperature from: -40°C
Operating temperature range up to: 140°C
Mounting method: DIN rail mounting 35 mm
Standard: EN-60947-7-1
