ONKA 10mm2 spring rail connector terminal block DIN rail terminal 2-wire blue, 1020047
- Regular price
- €1,48
- Regular price
-
- Sale price
- €1,48
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
- Description
- Payment methods
- Warranty
Spring rail connector / DIN rail terminal 2 wires, retractable contact, blue, ONKA, made in Turkey.
The ONKA coupler/terminal is a reliable solution for anyone looking for functional and durable elements in electrical installations.
Made from high-quality materials, the coupler ensures long-term use and resistance to mechanical damage.
Technical parameters
Single wire cross-section connected up to: 10mm2
Color: blue
Main housing insulating material: polyamide (PA6.6)
Contact/bridge material: stainless steel/copper
Connection position: top / top
Stripping length of cable: 12 mm
Type of electrical connection: spring clamp / retractable contact
Rated voltage: 750V
Rated current: 57A
Operating temperature from: -40°C
Operating temperature range up to: 140°C
Mounting method: DIN rail mounting 35 mm
Standard: EN-60947-7-1
