ONKA 1.5mm2 Connection terminal for screw rail Terminal for DIN rail 2-wire gray, 1010002

Online payment by card - after completing your order, you will be redirected to the payment gateway, payment confirmation will be sent to you by email

Cash on delivery - payment according to the payment regulations will be made to the delivery person of the transport company

By bank transfer - you will receive a pro forma invoice by email no later than the next working day, on which you will find the account number to enter when paying.

On invoice - this payment option is reserved for partners who have signed a framework contract with our company.

If you wish to use the last 2 methods, please call our manager and he will give you instructions on how to obtain an invoice with or without VAT.

The electrical appliances we supply meet high quality standards, have a 24-month warranty and comply with all EU requirements.

In the event of a complaint, no fees are charged for the return of goods.

Threaded connector for bar rail / terminal for DIN rail 2 wires gray, ONKA, made in Turkey

ONKA's compact installation rail couplers offer great possibilities for connecting any wire of different sections. The transparent housing allows for easy verification of the correct arrangement of wires. ONKA's original quick connectors facilitate installation and ensure 100% connection reliability.

Technical parameters

Connected wire section up to: 1.5mm2
Color: gray
Main housing insulating material: polyamide (PA6.6)
Contact/bridge material: steel/copper CK45
Tightening torque: 0.4 Nm
Connection position: side
Stripping length of cable: 10 mm
Type of electrical connection: screw collar
Rated voltage: 750V
Rated current: 17.5A
Operating temperature from: -40°C
Operating temperature range up to: 140°C
Mounting method: DIN mounting rail 35 mm
Standard: EN-60947-7-1
