ONKA 1.5mm2 Connection terminal for screw rail Terminal for DIN rail 2-wire blue, 1010005
- Regular price
- €0,52
- Regular price
-
- Sale price
- €0,52
- Unit price
- per
Couldn't load pickup availability
Notified by email when this product becomes available
- Description
- Payment methods
- Warranty
Threaded connector for bar rail / terminal for DIN rail 2 wires blue, ONKA, made in Turkey
The coupler / terminal ONKA is a reliable solution for anyone looking for functional and durable elements in electrical installations.
Made from high-quality materials, the connector ensures long-term use and resistance to mechanical damage.
Technical parameters
Single wire cross-section connected up to: 1.5mm2
Color: blue
Main housing insulating material: polyamide (PA6.6)
Contact/jumper material: steel/copper CK45
Tightening torque: 0.4 Nm
Connection position: side
Stripping length of cable: 10 mm
Type of electrical connection: screw collar
Rated voltage: 750V
Rated current: 17.5A
Operating temperature from: -40°C
Operating temperature range up to: 140°C
Mounting method: DIN rail mounting 35 mm
Standard: EN-60947-7-1
