ONKA 2.5mm2 screw connection fuse holder (fuse not included) gray, 1020223
Used to protect low current alternating or direct circuits. A 5x20 mm fuse is installed in the terminal with a current setting up to 6.3 A. The fuse is not included and must be ordered separately.
Technical parameters
Single wire cross-section connected up to: 2.5 mm2
Color: gray
Main housing insulating material: polyamide (PA6.6)
Contact/jumper material: stainless steel/copper
Connection position: top / top
Cable strip length: 9 mm
Type of electrical connection: screw collar
Rated voltage: 750V
Rated current: 6.3A
Operating temperature from: -40°C
Operating temperature range up to: 140°C
Mounting method: DIN rail mounting 35 mm
Standard: EN-60947-7-1
