TENSE

Network analyzer panel current, voltage, frequency, power, energy, RS485

In stock - 27 items available
SKU: TPM-04SHDL
€133,60 Price including VAT

Online payment by card - after completing your order, you will be redirected to the payment gateway, payment confirmation will be sent to you by email

Cash on delivery - payment according to the payment regulations will be made to the delivery person of the transport company

By bank transfer - you will receive a pro forma invoice by email no later than the next working day, on which you will find the account number to enter when paying.

On invoice - this payment option is reserved for partners who have signed a framework contract with our company.

If you wish to use the last 2 methods, please call our manager and he will give you instructions on how to obtain an invoice with or without VAT.

The electrical appliances we supply meet high quality standards, have a 24-month warranty and comply with all EU requirements.

In the event of a complaint, no fees are charged for the return of goods.

Three-phase network parameter analyzer / Network analyzer / Network analyzer - multifunction digital panel meter, current, voltage, frequency and total power indicator, with relay output, RS485 ModBus RTU - TPM-04SHDL manufacturer TENSE (Turkey) panel meters.

Power analyzers are designed to measure and monitor electrical values. Thanks to the communication function, energy measurements can be monitored and reported independently. Energy analyzers allow for analyses such as power quality, efficiency, and unit cost calculations.

Main advantages:

  • RS485 Modbus RTU (1200-19200bps)
  • Three-phase voltage transformer and three-phase current transformer.

  • Display of voltage and current harmonics up to the 31st harmonic.

  • Display of active power per phase (P)

  • Displays reactive power per phase (Q, inductive and capacitive)

  • Displays apparent powers per phase (S)

  • Displays the Cosφ and power factor values of each phase

  • Displays phase-neutral, phase-phase voltage (V) and current (I) values of each phase, measuring the frequency.

  • Displays the total active energy import and export values (ΣkWh)

  • Display of total inductive and capacitive reactive energy values (ΣkVArh)

  • Display of minimum and maximum values, maximum requirement

  • 2 relay outputs, 1 digital input

  • Event logs (high/low voltage/current, voltage/current unbalance, THD-I)

  • The menu is password protected.

This network analyzer is typically used with current measuring transformers - 60/5 75/5 100/5 150/5 200/5 250/5 300/5 400/5 500/5 600/5 800/5 1000/5 1500/5 or similar. If you intend to connect the analyzer to ModBus, we will send you a "Register Table" with ModBus addresses upon request.
